Product Summary
Parametrics
Jack-detect function to mute LINE/MONO/HP output, to control S/PDIF output.
Supports S/PDIF out is compliant with AC’97 rev2.2.
2 GPIO pins.
14.318MHz?24.576MHz digital PLL.
Supports double sampling rate (96KHz) of DVD audio playback.
+30dB boost preamplifier for MIC input.
Power support: Digital: 3.3V Analog: 3.3V/5V
Standard 48-Pin LQFP Package
Features
Single chip audio CODEC with high S/N ratio (>90 dB).
20-bit DAC, 18-bit ADC.
Stereo full-duplex CODEC with independent and variable sampling rate.
4 analog line-level stereo input with 5-bit volume control : LINE_IN,CD,VIDEO,AUX
2 analog line-level mono input : PC_BEEP,PHONE_IN.
Mono output with 5-bit volume control.
Stereo output with 6-bit volume control.
2 MIC inputs: Software selectable.
Power management and enhanced power saving.
3D Stereo Enhancement
External Amplifier power down capability.
Multiple CODEC extension.
Compliant with AC’97 2.2 specification
50mW/8W amplifier at LINE/ Headphone output
