Product Summary

  • The SKM100GB128D is an electrostatic discharge sensitive device (ESDS), international standard IEC 60747-1, Chapter IX.No warranty or guarantee expressed or implied is made regarding performancey,deliver or suitability ,The technical information specifies semiconductor devices but promises no characteristics.

    • Parametrics

    SKM100GB128D absolute maximum ratings: (1)VCES: 1200V; (2)IC: 100(90)A; (3)ICRM:150A; (4)VGES: ±20V; (5)TVJ(TSTG): -40...+150(125)°C; (6)VISOL: 2500V.

    Features

    SKM100GB128D features: (1)SPT=Solt-Punch-tHROUGH technology; (2)V cesalt with positive temperature coefficient; (3)High short circuit capability,self limiting to 6 x Ic.

    Diagrams

    SKM100GB128D block diagram
