Product Summary

(4) Vorwarts－ und Ruckwarts－Sperrstrom forward off－state and reverse current Tvj = Tvj max vD = VDRM, vR = VRRM iD, iR: max. 50 mA; (5) Zundverzug gate controlled delay time DIN IEC 747－6 Tvj = 25 ℃,iGM = 1 A, diG/dt = 1 A/μs tgd: max. 3 μs.

Parametrics

TD250N14KOF absolute maximum ratings: (1)Dauergrenzstrom average on－state current TC = 85℃, TC = 82℃ ITAVM: 250, 261A; (2)Stobstrom－Grenzwert surge current Tvj = 25 ℃, tP = 10 ms, Tvj = Tvj max, tP = 10 ms ITSM: 8000 7000A; (3)Grenzlastintegral I2t－value Tvj = 25 ℃, tP = 10 ms, Tvj = Tvj max, tP = 10 ms I2t: 320000, 245000A2s; (4)Kritische Stromsteilheit critical rate of rise of on state current DIN IEC 747－6 f = 50 Hz, iGM = 1 A, diG/dt = 1 A/μs(diT/dt)cr: 150 A/μs.

Features

TD250N14KOF features: (1) Nicht zundende Steuerspannung gate non－trigger voltage Tvj = Tvj max , vD = 0,5 VDRM VGD: max. 0,2 V; (2) Haltestrom holding current Tvj = 25℃, vD = 6 V, RA = 5 Ω IH: max. 300 mA; (3) Einraststrom latching current Tvj = 25℃, vD = 6 V, RGK . 10 Ω iGM = 1 A, diG/dt = 1 A/μs, tg = 20 μs IL: max. 1200 mA;

Diagrams

<IMG alt=" TD250N14KOF dimension" src="http://www.seekic.com/uploadfile/ic-mfg/201212325231875.jpg" border=0>

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TD250N14KOF
TD250N14KOF
Infineon Technologies
Discrete Semiconductor Modules 1400V 410A
Data Sheet
0-4: $109.16
4-10: $98.24
